Spring Energized Seal
Teflon Spring Energized Seal Design For Rotative Radial
Product Name: Teflon Spring Energized Seal Design for Rotative Radial
Product Introduction:
The Teflon material used in this design is known for its excellent chemical resistance and low coefficient of friction, making it ideal for use in applications where there are aggressive chemicals or high temperatures. Additionally, the spring energized design of this seal ensures that it maintains its sealing performance even in challenging environments.
In a radial rotary application, the Teflon Spring Energized Seal is designed to provide a positive seal against the rotating shaft while accommodating for any misalignment or runout that may be present. The spring-loaded design allows the seal to maintain contact with the rotating surface, even when there is a slight wobble or deflection in the shaft.
Overall, the Teflon Spring Energized Seal is an effective sealing solution for a variety of radial rotary applications where chemical resistance, low friction, and reliable performance are essential.
PTFE radial shaft seals with one or more PTFE sealing lip(s) are designed to withstand aggressive environments, high temperatures, high pressures and dry running that traditional radial shaft seals made of elastomeric sealing lip materials cannot withstand. Many of the PTFE compounds are FDA approved. Main advantages of PTFE seals include:
Withstand pressures up to 3,5 MPa (500 psi)
Withstand dry running
High chemical resistance
Wide operating temperature range, –70 to +250 °C (–95 to +480 °F)
Withstand speeds up to 30 m/s (5 900 ft/min)
Application：
Aircraft, aerospace
Medical instrumentation
Liquid chromatography
Pumps, valves. Compressors and mechanical seals
Semicoductor manufacturing equipment
Petroleum and chemical process equipment
The selection of seal materials typically requires a compromise between advantages and disadvantages. There are hundreds of different PTFE materials with a variety of fillers. Common fillers include glass fibre, carbon, graphite, molybdenum disulphide, metal oxides and various polymers. Each possesses different properties, appropriate for different applications and service conditions. Common to all filled PTFE materials are their improved resistance to wear and deformation.
KAFLON can provide optimal sealing solution and professional serving for your demands.
